MS304-2A1I
2U2N, 1-Socket, OCP Compliant, High Flexibility Multi-Node Server
Key Features
| Form Factor | |
| Form Factor | |
|
Chassis Form Factor 2U 2-Node |
|
|
Chassis Dimension (W x H x D) 447 x 86.8 x 800 mm 17.6 x 3.4 x 31.5 inch |
|
|
Mainboard Form Factor M-SDNO Class A 335 |
|
|
Mainboard Dimension 210 (W) x 335.59 (L) x 1.93 (T) mm |
|
| Processor | |
| Processor | |
|
Number of Processors 1 |
|
|
Processor Type AMD EPYC™ 9005 |
|
|
Max. TDP Support 500W |
|
| Memory | |
| Memory | |
|
Total Slots 12 |
|
|
Memory Type 1DPC: DDR5 RDIMM up to 6400 MT/s |
|
|
DIMM Capacity <br>(GB per DIMM) 32GB, 64GB, 96GB |
|
| Expansion Slots | |
| Expansion Slots | |
|
SKU - #1 2 x PCIe 5.0 x16 FHFL single width slots |
|
| Storage Bays | |
| Storage Bays | |
|
SKU - #1 4 x E1.S NVMe drives |
|
| Onboard Storage | |
| 2 x M.2 22110 / 2280 PCIe 5.0 or 4.0 x4 for booting | |
| Onboard Storage | 2 x M.2 22110 / 2280 PCIe 5.0 or 4.0 x4 for booting |
| Management | |
| Aspeed AST2600 | |
| Management | Aspeed AST2600 |
| Security | |
| TPM 2.0 | |
| Security | TPM 2.0 |
| Networking Interface | |
|
1 x IPMI RJ-45 1 x OCP 3.0 NIC, supports NC-SI |
|
| Networking Interface |
1 x IPMI RJ-45 1 x OCP 3.0 NIC, supports NC-SI |
| Front I/O Ports | |
|
1 x USB 3.0 type A port 1 x USB 2.0 type A port 1 x USB type C (UART) 1 x Mini Display Port 1 x Power button with LED 1 x UID button with LED 1 x BMC Status with LED |
|
| Front I/O Ports |
1 x USB 3.0 type A port 1 x USB 2.0 type A port 1 x USB type C (UART) 1 x Mini Display Port 1 x Power button with LED 1 x UID button with LED 1 x BMC Status with LED |
| OS Support | |
|
Ubuntu 22.04 LTS or later version RedHat RHEL 9.4 or later Windows Server 2022/2025 VMware 8.0 |
|
| OS Support |
Ubuntu 22.04 LTS or later version RedHat RHEL 9.4 or later Windows Server 2022/2025 VMware 8.0 |
| Power Supply | |
| 1+1 2400W CRPS | |
| Power Supply | 1+1 2400W CRPS |
| Fans | |
| 4 x 8056 Fans | |
| Fans | 4 x 8056 Fans |
| Operating Environment | |
|
Ambient operating temperature range: 10°C to 35 °C Ambient Non-operating temperature: -40°C to 70 °C Operating relative humidity: 10% to 80%, non-condensing Non-operating relative humidity: up to 90%, non-condensing |
|
| Operating Environment |
Ambient operating temperature range: 10°C to 35 °C Ambient Non-operating temperature: -40°C to 70 °C Operating relative humidity: 10% to 80%, non-condensing Non-operating relative humidity: up to 90%, non-condensing |
