NEW
GS205-2A2E
2U Dual-Socket AMD EPYC™ 9006 Series (Venice SP7) Server
High Performance Compute Platform for Enterprise and Cloud Data Center Workloads
Key Features
| Form Factor | |
| Form Factor | |
|
Chassis Form Factor 2U |
|
|
Chassis Dimension (W x H x D) 448 x 87 x 815 mm 17.6 x 3.4 x 32.1 inch |
|
|
Mainboard Form Factor M-FLW |
|
|
Mainboard Dimension 423.2 x 348 mm |
|
| Processor | |
| Processor | |
|
Number of Processors 2 |
|
|
Processor Type AMD EPYC™ 9006 server series processors (Venice SP7) |
|
|
Max. TDP Support 600W |
|
| GPU | |
| Up to 2 x dual-slot PCIe GPUs, TDP up to 350W | |
| GPU | Up to 2 x dual-slot PCIe GPUs, TDP up to 350W |
| Memory | |
| Memory | |
|
Total Slots 32 |
|
|
Memory Type DDR5 RDIMM/MRDIMM, 1DIMM per channel RDIMM: 8000 MT/s MRDIMM: 12800 MT/s |
|
|
DIMM Capacity (GB per DIMM) 64GB, 96GB, 128GB, 256GB |
|
| Expansion Slots | |
|
1 x PCIe 6.0 x16 OCP 3.0 2 x PCIe 6.0 x16 FHFL double-slot 2 x PCIe 6.0 x16 FHHL single-slot |
|
| Expansion Slots |
1 x PCIe 6.0 x16 OCP 3.0 2 x PCIe 6.0 x16 FHFL double-slot 2 x PCIe 6.0 x16 FHHL single-slot |
| Storage Bays | |
| 12 x PCIe 6.0 E3.S | |
| Storage Bays | 12 x PCIe 6.0 E3.S |
| Onboard Storage | |
| 2 x PCIe 4.0 M.2 2280/22110 NVMe | |
| Onboard Storage | 2 x PCIe 4.0 M.2 2280/22110 NVMe |
| Management | |
| Aspeed AST2700 | |
| Management | Aspeed AST2700 |
| Security | |
| TPM 2.0 | |
| Security | TPM 2.0 |
| Networking Interface | |
| 1 x IPMI RJ45 | |
| Networking Interface | 1 x IPMI RJ45 |
| Front I/O Ports | |
|
1 x Power Button/LED 1 x UID Button/LED 1 x BMC Status/LED 1 x USB 2.0 |
|
| Front I/O Ports |
1 x Power Button/LED 1 x UID Button/LED 1 x BMC Status/LED 1 x USB 2.0 |
| Rear I/O Ports | |
|
1 x IPMI RJ45 2 x USB 3.0 Type-A 1 x Type-C Console 1 x MiniDP Reset Button UID Button/LED Power Button/LED Status LED |
|
| Rear I/O Ports |
1 x IPMI RJ45 2 x USB 3.0 Type-A 1 x Type-C Console 1 x MiniDP Reset Button UID Button/LED Power Button/LED Status LED |
| OS Support | |
|
Ubuntu 24.04 / 26.x LTS latest version RedHat RHEL 9.x /10.x latest version |
|
| OS Support |
Ubuntu 24.04 / 26.x LTS latest version RedHat RHEL 9.x /10.x latest version |
| Power Supply | |
| 1+1 3200W Titanium CRPS / M-CRPS | |
| Power Supply | 1+1 3200W Titanium CRPS / M-CRPS |
| Fans | |
| 6 x 6056 fans | |
| Fans | 6 x 6056 fans |
