NEW
MS303-2A1G-P60
2OU 2-Socket, Liquid-Cooled, OCP Compliant, NVIDIA RTX PRO™ 6000 Blackwell Server Edition 4-GPU, Supercharging Generative AI and High-Performance Computing
Key Features
| Form Factor | |
| Form Factor | |
|
Chassis Form Factor 2OU |
|
|
Chassis Dimension (W x H x D) 537 x 93.5 x 809.25 mm 21.1 x 3.7 x 31.9 inch |
|
| Processor | |
| Processor | |
|
Number of Processors 2 |
|
|
Processor Type AMD EPYC™ 9005 processors |
|
|
Max. TDP Support 500W |
|
| GPU | |
| 4 x NVIDIA RTX PRO™ 6000 Blackwell Server Edition (Liquid-Cooled) | |
| GPU | 4 x NVIDIA RTX PRO™ 6000 Blackwell Server Edition (Liquid-Cooled) |
| Memory | |
| Memory | |
|
Total Slots 24 x DDR5 DIMM slots |
|
|
Memory Type 1DPC: DDR5 RDIMM, 6400 MT/s |
|
| Expansion Slots | |
| Expansion Slots | |
|
SKU -#1 2 x PCIe 5.0 x16 OCP 3.0 2 x PCIe 5.0 x8 OCP 3.0 |
|
| Storage Bays | |
| Storage Bays | |
|
SKU - #1 2 x E1.S NVMe (w/ HW RAID 1 for OS) 8 x E3.S NVMe |
|
| Management | |
| DC-SCM 2.0 (Aspeed AST2600) | |
| Management | DC-SCM 2.0 (Aspeed AST2600) |
| Security | |
|
TPM 2.0 PROT (optional, Aspeed AST1060) |
|
| Security |
TPM 2.0 PROT (optional, Aspeed AST1060) |
| Networking Interface | |
|
4 x OCP 3.0 2 x 1GbE RJ45 (DC-SCM) 1 x IPMI RJ45 (DC-SCM) |
|
| Networking Interface |
4 x OCP 3.0 2 x 1GbE RJ45 (DC-SCM) 1 x IPMI RJ45 (DC-SCM) |
| Front I/O Ports | |
|
DC-SCM 2.0-like module (AST2600) 2 x 1GbE RJ45 1 x IPMI RJ45 1 x Micro USB COM port 1 x USB 2.0 Type-C 1 x MiniDP Power button LED / UID button LED / reset button / status button |
|
| Front I/O Ports |
DC-SCM 2.0-like module (AST2600) 2 x 1GbE RJ45 1 x IPMI RJ45 1 x Micro USB COM port 1 x USB 2.0 Type-C 1 x MiniDP Power button LED / UID button LED / reset button / status button |
| Power Supply | |
| ORv3 48VDC busbar | |
| Power Supply | ORv3 48VDC busbar |
| Fans | |
|
Liquid-cooled 2 x fans |
|
| Fans |
Liquid-cooled 2 x fans |
