NEW
MS303-2A1G
2OU, 2-Socket AMD EPYC™ (Turin) GPU Server, Accelerated by NVIDIA HGX™ H200 4-GPU
Build for Supreme Performance and Eco-Friendly with Liquid Cooling Solution
Key Features
| Form Factor | |
| Form Factor | |
|
Chassis Form Factor 2OU |
|
|
Chassis Dimension (mm) 537 (W) × 93.5 (H) × 809.25 (D) |
|
|
Mainboard Form Factor Half-width MB |
|
|
Mainboard Dimension (mm) 540 x 250 |
|
| Processor | |
| Processor | |
|
Number of Processors 2 |
|
|
Processor Type AMD EPYC™ 9005 series processors |
|
|
Max. TDP Support 500W |
|
| GPU | |
| NVIDIA HGX™ H200 4-GPU | |
| GPU | NVIDIA HGX™ H200 4-GPU |
| Memory | |
| Memory | |
|
Total Slots 24 |
|
|
Memory Type 1DPC: DDR5 RDIMM up to 6400 MT/s |
|
|
DIMM Capacity (GB per DIMM) 64GB, 96GB, 128GB |
|
| Expansion Slots | |
| Expansion Slots | |
|
SKU - #1 2 x PCIe 5.0 x16 OCP 3.0 2 x PCIe 5.0 x8 OCP 3.0 2 x PCIe 5.0 ×16 HHHL |
|
| Storage Bays | |
| Storage Bays | |
|
SKU - #1 2 x E1.S NVMe SSD (support hardware RAID 1 for OS) 8 x E3.S 1T NVMe SSD |
|
| Management | |
| Aspeed® AST2600 | |
| Management | Aspeed® AST2600 |
| Security | |
|
TPM 2.0 PROT (optional module, ASPEED AST1060) |
|
| Security |
TPM 2.0 PROT (optional module, ASPEED AST1060) |
| Networking Interface | |
|
4 x OCP 3.0 NIC 1 x BMC management RJ45 (DC-SCM) 2 x RJ45 1GbE LAN (DC-SCM) |
|
| Networking Interface |
4 x OCP 3.0 NIC 1 x BMC management RJ45 (DC-SCM) 2 x RJ45 1GbE LAN (DC-SCM) |
| Front I/O Ports | |
|
DC-SCM 2.0-like module (AST 2600) 1 x BMC management RJ45 2 x RJ45 1GbE LAN 1 x Micro USB 1 x USB 2.0 Type-C 1 x Mini display port 1 x Power button LED 1 x UID button LED 1 x BMC reset button 1 x System status button |
|
| Front I/O Ports |
DC-SCM 2.0-like module (AST 2600) 1 x BMC management RJ45 2 x RJ45 1GbE LAN 1 x Micro USB 1 x USB 2.0 Type-C 1 x Mini display port 1 x Power button LED 1 x UID button LED 1 x BMC reset button 1 x System status button |
| OS Support | |
|
Ubuntu 22.04 LTS and above RHEL 8.6 and above VMware ESXi8.0, Linux Enterprise Server (SLES): 15 SP5 and above Windows Server 2022 |
|
| OS Support |
Ubuntu 22.04 LTS and above RHEL 8.6 and above VMware ESXi8.0, Linux Enterprise Server (SLES): 15 SP5 and above Windows Server 2022 |
| Power Supply | |
| ORv3 48VDC Busbar | |
| Power Supply | ORv3 48VDC Busbar |
| Fans | |
| 2 x 9256 Fan + Direct Liquid Cooling | |
| Fans | 2 x 9256 Fan + Direct Liquid Cooling |
| Operating Environment | |
|
Operating Temperature: 10°C to 35°C Storage temperature range: -40°C to 60 °C Non-operation relative humidity: 10% to 90%, non-condensing |
|
| Operating Environment |
Operating Temperature: 10°C to 35°C Storage temperature range: -40°C to 60 °C Non-operation relative humidity: 10% to 90%, non-condensing |
