NEW
AS801-2T1-8H2
8U 2-Socket NVIDIA HGX™ B300 8-GPU System
Built for the Age of AI Reasoning for Every Data Center
Key Features
| Form Factor | |
| Form Factor | |
|
Chassis Form Factor 8U |
|
|
Chassis Dimension (mm) 448 (W) x 353.6 (H) x 930 (D) |
|
| Processor | |
| Processor | |
|
Number of Processors 2 |
|
|
Processor Type Intel® Xeon® 6700E/6700P processors |
|
|
Max. TDP Support 350W |
|
| GPU | |
| NVIDIA HGX™ B300 8-GPU, 1200W TDP | |
| GPU | NVIDIA HGX™ B300 8-GPU, 1200W TDP |
| Memory | |
| Memory | |
|
Total Slots 32 |
|
|
Memory Type 1DPC: DDR5 RDIMM, 6400 MT/s 2DPC: DDR5 RDIMM, 5200 MT/s |
|
|
DIMM Capacity <br>(GB per DIMM) RDIMM: up to 128GB (2R) RDIMM-3DS: up to 256GB |
|
| Expansion Slots | |
| Expansion Slots | |
|
SKU - #1 4 x PCIe 5.0 x16 FHHL |
|
| Storage Bays | |
| Storage Bays | |
|
SKU - #1 12 x 2.5” NVMe SSD PCIe 5.0 x4 |
|
| Onboard Storage | |
| 1 x M.2 2280/22110 NVMe | |
| Onboard Storage | 1 x M.2 2280/22110 NVMe |
| Management | |
| Aspeed® AST2600 | |
| Management | Aspeed® AST2600 |
| Security | |
| TPM 2.0 | |
| Security | TPM 2.0 |
| Networking Interface | |
|
2 x 1GbE RJ45 1 x IPMI RJ45 |
|
| Networking Interface |
2 x 1GbE RJ45 1 x IPMI RJ45 |
| Front I/O Ports | |
|
8 x NVIDIA ConnectX®-8 OSFP Ports (800Gb/s) 2 x 1GbE RJ45 1 x IPMI RJ45 4 x USB 3.0 1 x VGA 1 x Power button LED |
|
| Front I/O Ports |
8 x NVIDIA ConnectX®-8 OSFP Ports (800Gb/s) 2 x 1GbE RJ45 1 x IPMI RJ45 4 x USB 3.0 1 x VGA 1 x Power button LED |
| Rear I/O Ports | |
|
2 x Type-A USB3.0 1 x VGA |
|
| Rear I/O Ports |
2 x Type-A USB3.0 1 x VGA |
| OS Support | |
|
Windows Server Linux VMware ESXi |
|
| OS Support |
Windows Server Linux VMware ESXi |
| Power Supply | |
| 6+6 3000W Titanium CRPS | |
| Power Supply | 6+6 3000W Titanium CRPS |
| Fans | |
| 31 x 8080 fans | |
| Fans | 31 x 8080 fans |
| Operating Environment | |
|
Operating Temperature: 10°C ~ 35°C Non-operating temperature: -40°C ~ 70°C |
|
| Operating Environment |
Operating Temperature: 10°C ~ 35°C Non-operating temperature: -40°C ~ 70°C |
