AS501-4A1-16I1
5OU, 16-GPU, Ultra High-Density Liquid Cooled System AMD Instinct™ MI355X GPU, Advanced Direct Liquid Cooled GPU Solution for AI, Inference, and Training
- ⦁ 2x CPU Node: AMD EPYC™ 9005 Processors Dual Socket
- ⦁ 2x GPU Tray: AMD Instinct™ MI355X 8-GPU
- ⦁ CPU Memory: 12x DDR5 DIMM Slots per CPU, 96GB DDR5 RDIMM (6400MT/s)
- ⦁ GPU Memory: 288GB HBM3e per GPU
- ⦁ Networking: 5x 400Gb/s NICs (single-port) per node (10 per system), 1x 10Gb/s NIC (dual-port) per node (2 per system)
Key Features
- 1. 2x CPU Node: AMD EPYC™ 9005 Processors Dual Socket
- 2. 2x GPU Tray: AMD Instinct™ MI355X 8-GPU
- 3. CPU Memory: 12x DDR5 DIMM Slots per CPU, 96GB DDR5 RDIMM (6400MT/s)
- 4. GPU Memory: 288GB HBM3e per GPU
- 5. Networking: 5x 400Gb/s NICs (single-port) per node (10 per system), 1x 10Gb/s NIC (dual-port) per node (2 per system)
| Form Factor | |
| Form Factor | |
|
Chassis Form Factor 5OU (2+1+2) |
|
|
Chassis Dimension (mm) 537 (W) x 237.5 (H) x 809.25 (D) |
|
| Processor | |
| Processor | |
|
Number of Processors 2+2 |
|
|
Processor Type AMD EPYC™ 9005 processors |
|
|
Max. TDP Support 500W |
|
| GPU | |
| 1+1 AMD Instinct™ MI355X 8-GPU | |
| GPU | 1+1 AMD Instinct™ MI355X 8-GPU |
| Memory | |
| Memory | |
|
Total Slots CPU: 24+24 DIMM slots |
|
|
Memory Type 1DPC: DDR5 RDIMM, 6400 MT/s |
|
|
DIMM Capacity <br>(GB per DIMM) GPU: 8+8 288GB HBM3e |
|
| Expansion Slots | |
| Expansion Slots | |
|
SKU - #1 6+6 PCIe 5.0 x16 FHHL: for 5+5 400G NIC (single-port) & 1+1 10G NIC (dual-port) |
|
| Onboard Storage | |
| 1+1 x M.2 2280/22110 NVMe | |
| Onboard Storage | 1+1 x M.2 2280/22110 NVMe |
| Management | |
| DC-SCM 2.0 (Aspeed® AST 2600) | |
| Management | DC-SCM 2.0 (Aspeed® AST 2600) |
| Security | |
|
TPM 2.0 PROT (optional, ASPEED AST1060) |
|
| Security | TPM 2.0 PROT (optional, ASPEED AST1060) |
| Networking Interface | |
|
2x 1GbE RJ45 (DC-SCM) 1x IPMI RJ45 (DC-SCM) |
|
| Networking Interface | 2x 1GbE RJ45 (DC-SCM) 1x IPMI RJ45 (DC-SCM) |
| Front I/O Ports | |
|
2x 1GbE RJ45 1x IPMI RJ45 1 x Micro USB COM Port 1 x USB 2.0 Type-C 1 x MiniDP 1 x Power button LED |
|
| Front I/O Ports | 2x 1GbE RJ45 1x IPMI RJ45 1 x Micro USB COM Port 1 x USB 2.0 Type-C 1 x MiniDP 1 x Power button LED |
| Power Supply | |
| ORv3 48VDC Busbar | |
| Power Supply | ORv3 48VDC Busbar |
| Fans | |
| 10 x fans | |
| Fans | 10 x fans |
